Stainless steel braided hose is an industrial metal material with good bending performance, good temperature resistance and pressure resistance. Classification by use: mainly including metal corrugated pipes, bellows expansion joints, corrugated heat exchange pipes, etc. The metal bellows is made of thin-walled stainless steel welded pipe by corrugated processing, which has flexibility and good temperature and pressure resistance. It is suitable for the transportation of various industrial gases such as air and steam, and various fluid media such as water, oil, and medicine.It plays an important role in the reciprocating motion of the piping system, absorption of thermal expansion, vibration absorption, and center adjustment of piping.

Stainless steel braided hose is composed of corrugated pipe, outer braided steel wire layer and various types of joints.

According to the different types of corrugated pipes, ss braided hose mainly divided into two types, one is an annular corrugated hose, and the other is a spiral corrugated pipe.
Spiral corrugated pipe:
Spiral corrugated pipe is a tubular shell with corrugations arranged in a spiral. There is a helix angle between two adjacent corrugations, and all corrugations can be connected by a helical line.
Annular corrugated hose:
Annular corrugated hose is a tubular shell with closed annular corrugations, and the waves are formed by series of annular corrugations. The annular corrugated hose is formed from seamless pipe or welded pipe. Restricted by the processing method, the length of the single hose is usually shorter than that of the spiral corrugated pipe. The advantages of annular corrugated hose are good elasticity and low stiffness.

Features of stainless steel braided hose:
1. Good construction: The stainless steel braided hose is a thin-walled hose, and the overall weight is reduced, which greatly reduces the load of construction work and reduces construction time.
2. Corrosion resistance: The main body of the braided hose is formed of 304 or 316L stainless steel, with stainless steel joints or carbon steel joints at both ends, which has good corrosion resistance.
3. High pressure resistance: Considering various factors such as the actual working pressure of the bellows, the use environment and use conditions, all parameters have been carefully calculated and tested repeatedly to ensure the safety of its pressure at work.
4. Various types: Existing bellows diameter range: DN8-DN4000, others can be customized according to customer requirements.
5. Anti-shock and anti-displacement: The stainless steel braided hose has the characteristics of good flexibility and compensation for displacement.

Stainless steel braided hoses are mainly used for compensating pipeline thermal deformation, shock absorption, absorbing pipeline settlement deformation, etc., and are widely used in petrochemical, instrumentation, aerospace, chemical, electric power, cement, metallurgy and other industries.

dinghong can provide stainless steel braided hose assembly with all kinds of fittings, such as thread, flange, camlock quick coupling, sanitary tri clamp, union, welded pipe ends, etc. the ss braided hose length can be special customized according to your requirements, you can call us for more information.
